AquaForce® Air-Cooled Screw Chiller 30XA

AquaForce® Air-Cooled Screw Chiller 30XA

The AquaForce® 30XA chillers, available in capacities from 80 to 500 nominal tons, are engineered to meet today’s and tomorrow’s efficiency standards, providing premium air-cooled chiller solutions for contractors, consulting engineers, and building owners. Featuring rotary screw compressors and using R-134a HFC refrigerant, these chillers deliver quiet operation thanks to the AeroAcoustic™ fan system, while offering user-friendly ComfortLink™ controls and advanced microchannel condenser coil technology for superior performance.

These air-cooled chillers are certified under the AHRI Air-Cooled Water-Chilling Packages Certification Program, complying with AHRI Standard 550/590 (I-P) and AHRI Standard 551/591 (SI). Verified units can be found in the AHRI Directory at www.ahridirectory.org.

carrier-30XA-air-cooled-liquid-chiller

Performance Features

  • Full-load EER values up to 10.9 and IPLV values up to 15.5
  • ASHRAE 90.1 compliant / AHRI certified
  • Operation from -20 F to 125°F ambient conditions
  • High-efficiency screw compressors
  • Standard uncoated or optional e-coated Novation® microchannel heat exchanger (MCHX) condenser coils
  • Touch Pilot™ display with color touch screen with trending capability and web-based connection

Reliability Features

  • ASME constructed evaporators / ETL (and ETL Canada) listed
  • Heavy-gauge galvanized steel frame
  • Security grilles and Hail guards/Privacy screen choices
  • Low ambient head pressure control
  • Coil corrosion coatings available on all coil types
  • High short circuit current rating
  • EXV (Electronic expansion valve)

Maintenance Features

  • Over 15 diagnostic functions
  • Permanently lubricated fan motor bearings
  • Compressor suction service valves
  • Microchannel condenser coils with inherent corrosion resistance and offering simplified cleaning
  • Unit-mounted, non-fused disconnect
  • Remote service port for easier machine diagnostics

Installation Features

  • Factory charged with R-134a refrigerant
  • GFI (ground fault interrupter) convenience outlet (factory-installed option or field-installed accessory)
  • Remote cooler kit (field-installed accessory)
  • Single or dual-point electrical connections available (factory-installed option)
  • Control transformer (factory-installed option)
  • Structurally robust base
  • Circuit setter provided with optional pump package (factory-installed option)

Factory-Installed Options

  • Service option
  • Condenser coil trim panels
  • Full end screen
  • Hydronic pump package with or without VFD (sizes 090-160)
  • Condenser coil options:
    • Microchannel Heat Exchanger:
      • Non-coated
      • E-coated
    • Aluminum fins:
      • Non-coated
      • Pre-coated
      • E-coated
    • Copper fins:
      • Non-coated
      • E-coated
  • Non-fused disconnect
  • Security grilles
  • Energy Management Module
  • Compressor sound reduction enclosures
  • Compressor suction service valve
  • Condenser coil upper hail guards
  • BACnet™ communication
  • BACnet™ translator control
  • LON (local operating network) translator control
  • Low ambient temperature head pressure control
  • Single or dual-point electrical connection
  • High ambient temperature option
  • Touch Pilot™ display
  • Navigator™ display
  • DX cooler
  • Minus-one-pass cooler (flooded cooler only)
  • Plus-one-pass cooler (flooded cooler only)
  • Control transformer
  • Suction line insulation
  • High short circuit current rating

Field-Installed Accessories

  • Security grilles
  • Condenser coil full hail guards
  • Navigator™ display
  • GFI convenience outlet
  • Energy Management Module
  • LON (local operating network) translator control
  • BACnet™ translator control
  • Remote service port
  • Remote cooler
  • Condenser coil trim panels
  • Dual-chiller accessory kit
  • External pump control

30XA Weights & Dimensions

SizeWeight (lb)Weight (kg)Length (in)Length (mm)Width (in)Width (mm)Height (in)Height (mm)
080723432811413587882236912300
082739133531413587882236912300
090812736861884780882236912300
092825137421884780882236912300
100834837861884780882236912300
102847238431884780882236912300
110848338481884780882236912300
112872039551884780882236912300
120862239111884780882236912300
122883240061884780882236912300
1401076848842355975882236912300
1421122550912355975882236912300
1601100049902355975882236912300
1621142651832355975882236912300
1801266957602827168882236912300
1821304459172827168882236912300
2001281058112827168882236912300
2021311259482827168882236912300
2201374862363298363882236912300
2221409263923298363882236912300
2401389763043298363882236912300
2421424164593298363882236912300
2601572071303769555882236912300
2621592272223769555882236912300
2801587872023769555882236912300
2821608072943769555882236912300
3001614173223769555882236912300
3021661375353769555882236912300
32517467792342310750882236912300
32717939813742310750882236912300
35017659801042310750882236912300
35218131822442310750882236912300
40120785942447011945882236912300
45121737985951713139882236912300
476253621064151713139882236912300
501274031154061115532882236912300

Notes

1) Indicated weight is for chiller employing MCHX condenser coils and incorporating no pump.
2) Other coil options or the addition of pump(s) increases chiller weight.
